100G SFP56-DD LR 1311nm 10km Optical Transceiver
The 100G SFP56-DD LR optical transceiver module is designed to deliver reliable high-speed 100 Gigabit Ethernet connectivity over single-mode fiber (SMF) links up to 10 kilometers.
Operating at a wavelength of 1311nm, the module complies with the SFP-DD MSA standard and is optimized for high-density data center, enterprise, and telecom networking applications. Integrated Digital Diagnostic Monitoring (DDM) functions are available through the I2C management interface in accordance with the SFP-DD MSA specification.
Product Features
• Supports up to 100Gbps data rate
• Transmission distance up to 10km over single-mode fiber
• 1311nm LAN-WDM optical technology
• SFP56-DD hot-pluggable form factor
• Fully compliant with SFP-DD MSA specifications
• Supports Digital Diagnostic Monitoring (DDM)
• Low power consumption and high reliability
• Designed for high-density 100G networking environments
• LC duplex optical connector
• Optimized for enterprise, telecom, and data center applications
Technical Specifications
• Form Factor: SFP-DD
• Data Rate: 100Gbps
• Transmission Distance: 10km
• Wavelength: 1311nm
• Optical Connector: LC Duplex
• Fiber Type: Single-Mode Fiber (SMF)
• Transmitter Type: LAN-WDM EML
• Receiver Type: PIN
• Operation Temperature: 0°C to 70°C (32°F to 158°F)
• Supply Voltage: 3.3V
• DDM Support: Yes
• Protocols: MSA Compliant
• Warranty: 5 Years
Key Features
Operate on Single lambda 100G
Single 3.3V power supply
SFP-DD MSA Compliant
1x106.25Gb/s(PAM4) optical interface
2x53.125Gb/s(PAM4) electrical interface
Class 1 FDA and IEC60825-1 Laser Safety Compliant
Operating Case Temperature Standard: 0~+70?
RoHS Compliant
I2C interface with integrated Digital Diagnostic Monitoring
