Key Features
Single wavelength 40Gbps transmission
Fixed wavelengths on DWDM 100GHz Grid
Up to 80km over SMF (with DCM and EDFA)
Duplex LC connector
Power dissipation 3.5W (Max)
4 x 10G Electrical interface at host side
Compliant with QSFP+ MSA SFF-8679
Compliant with QSFP+ MSA SFF-8636
QSFP+ MSA digital monitoring functions
Safety Certification: TUV/UL/FDA*Note1
RoHS Compliant
TX Power:+4.0~+7.0dBm
Receiver Sensitivity:< -26.0dBm
Powerbudget: 28dB
Warranty: 5 years


Application
40GbE signal DWDM transmission
