Key Features
QSFP-DD MSA compliant
Compliant to IEEE 802.3bs 400GBASE-LR8
Digital diagnostic monitoring support
Hot pluggable 76 pin electrical interface
8 LAN-WDM lanes MUX/DEMUX design
53.125Gbit/s PAM4 Channel Electrical Serial Interface (400GAUI-8)
Power Consumption: =10W
LC duplex connector
Supports 425Gb/s bit rate
Up to 10km transmission on single mode fiber
Operating case temperature:  0 to 70°C
Single 3.3V power supply
RoHS 2.0 compliant
Extinction Ratio: 3.5dB
TX Power: -2.8~5.3dBm
RX Power: -9.1~5.3dBm
Powerbudget: 6dB

Application
400G Ethernet IEEE 802.3bs 400GBASE-LR8
Telecom networking
Data Center Interconnection
