Key Features
Supports 425Gbps
Up to 2km over SMF
Duplex LC connector
8x53.125GBd(PAM4) electrical interface
Data Rate 106.25Gbps (PAM4) optical channel
QSFP112 MSA compliant
PIN and TIA array on the receiver side
Power Consumption: = 10W
Voltage: 3.3V
Case temperature range: 0°C to 70°C
Safety Certification: TUV/UL/FDA*1
RoHS Compliant
TX Power: -3.3~+3.5dBm
Receiver Sensitivity: < -7.7dBm
Powerbudget: 4dB
Application
4x100G FR applications
Data center
