Key Features
QSFP-DD MSA compliant
Parallel 4 Optical Lanes
IEEE802.3bs Specification compliant
Up to 500m transmission on single mode fiber (SMF) with FEC
Operating case temperature:  0 to 70°C
8x53.125Gb/s electrical interface (400GAUI-8)
Data Rate 106.25Gbps (PAM4) per channel.
Maximum power consumption 10W
MPO-12 connector
RoHS compliant
Transmitter Type: 1310nm EML
Receiver Type: PIN
TX Power: -2.9~+4.0dBm
Receiver Sensitivity: < -5.9dBm
Powerbudget: 3dB

Application
400G Ethernet IEEE 802.3bs 400GBASE-DR4
Data Center Intraconnection
