OSFP 800G FTF to 2x400G QSFP112 NDR IB

The 800G OSFP to 2x 400G QSFP112 InfiniBand NDR DAC Breakout Cable, Passive, OSFP to 2x QSFP112, 28AWG

The NVIDIA/Mellanox MCP7Y10-N0xx is a high-performance 2x 400Gb/s twin-port OSFP to 2x 400Gb/s twin-port QSFP112 Direct Attach Copper (DAC) breakout cable. The OSFP connector features an 8-lane twin-port finned-top form factor, optimized for deployment in Quantum-2 and Spectrum-4 switch platforms.
Each QSFP112 breakout connector supports 400Gbps throughput via four lanes of 100G-PAM4 signaling and uses a flat-top form factor, making it ideal for ConnectX-7 network adapters and BlueField-3 DPUs that integrate riding heat sinks on the connector cage.

This cable adheres to industry standards including OSFP MSA, QSFP112 MSA (Multi-Source Agreement), and IEEE 802.3ck, ensuring broad interoperability and reliable performance.
As a passive DAC, it is specifically designed for short-reach, high-speed interconnects in modern data center architectures. It provides ultra-low latency and extremely low power consumption, making it ideal for connecting servers, GPUs, and DPUs to top-of-rack (ToR) switches, as well as creating spine-to-super-spine links.
DACs are also widely used to build InfiniBand storage fabrics, providing high-throughput connectivity to both HDD and flash memory systems.

With its minimalist design and no active components, this DAC breakout cable delivers cost-effective, low-latency, and energy-efficient performance—maximizing port bandwidth, density, and scalability in hyperscale and supercomputing environments.

Technical Specifications – 800G OSFP to 2x 400G QSFP112 DAC Breakout Cable
• Form Factor: OSFP to 2x QSFP112
• Maximum Data Rate: 800Gbps (2x 400G)
• Media Type: Copper
• Cable Type: Passive Twinax
• Wire Gauge (AWG): 28AWG
• Minimum Bend Radius: 40.5mm
• Power Consumption: 0.1W
• Jacket Material: PVC (OFNR rated)
• Operating Temperature: 0°C to 70°C
• Supported Protocols:
o OSFP MSA
o QSFP112 MSA
o IEEE 802.3ck
o CMIS v5.0
• Modulation Format: PAM4
• Warranty: 5 years
