GLOBALfiber S25G-L20I-Cxx is a industrial-temperature 25G SFP28 CWDM optical transceiver for links up to 20 km over single-mode fiber. Each module uses one selected optical channel for wavelength-multiplexed Ethernet links.
Available coding and compatibility
Available coding: Arista, Cisco, Dell, Extreme, Fortinet, Generic, HP, Huawei, Intel, Juniper. Provide the equipment model, port configuration and software version so support can be checked. Coding does not confirm compatibility with every model or protocol. For other coding requirements, contact salg@globalfiber.no.
Key specifications
| Specification | Details |
|---|
| Product number | S25G-L20I-Cxx |
|---|
| Form factor | SFP28 |
|---|
| Capacity | 25G |
|---|
| Applications | 25G Ethernet |
|---|
| Power dissipation | 1.5 W |
|---|
| Reach and fiber | 20 km over single-mode fiber; host FEC required |
|---|
| Nominal wavelength | One selected CWDM channel: 1471, 1491, 1511, 1531, 1551, 1571, 1591, 1611 nm |
|---|
| Optical connectors | Duplex LC |
|---|
| Diagnostics | Digital optical monitoring (DOM/DDM) |
|---|
| Operating case temperature | -40°C to +85°C |
|---|
Installation requirements
Match the selected wavelength to the multiplexer and remote optical interface. Enable host FEC and verify the complete optical link budget.
