Key Features

0 to +2400 ps/nm Dispersion Tolerance (~120km reach without dispersion compensation)
Supports 9.95 to 11.3Gb/s bit rates
Hot-Pluggable
Duplex LC connector
1550nm cooled CML transmitter, APD photo-detector
SMF links up to 120km
2-wire interface for management specifications compliant with SFF 8472 digital diagnostic monitoring interface
Power Supply :+3.3V
Power consumption<1.8W
Temperature Range: 0~ 70°C
RoHS compliant
TX Power: +1.0~+5.0dBm
Receiver Type: < -25.0dBm
Powerbudget: 26dB


Application

10GBASE-ZR/ZW Ethernet
SONET OC-192 / SDH
10G Fiber channel
