Key Features

4 lanes MUX/DEMUX design
Integrated LAN WDM TOSA / ROSA
Up to 11.2Gbps per channel bandwidth
Aggregate bandwidth of > 40Gbps
Duplex LC connector
Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-ZR4
QSFP MSA compliant
APD photo-detector
Up to 80 km transmission
Compliant with QDR/DDR Infiniband data rates
Single +3.3V power supply operating
Built-in digital diagnostic functions
Temperature range 0°C to 70°C
RoHS Compliant Part
TX Power: +4.0~+7.0dBm
Receiver Sensitivity:< -26.0dBm
Powerbudget: 28dB

Application

Rack to rack
Data centers Switches and Routers
Metro networks
Switches and Routers
