Key Features
4 independent full-duplex channels
Up to 11.2Gbps per channel bandwidth
Aggregate bandwidth of > 40Gbps
MTP/MPO connector
Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-LR4 Standard
QSFP MSA compliant
Up to10km transmission
Compliant with QDR/DDR Infiniband data rates
Single +3.3V power supply operating
Built-in digital diagnostic functions
Temperature range 0°C to 70°C
RoHS Compliant Part
TX Power:-5~1dBm
Receiver Sensitivity: < -12.6dBm
Poerbudget: 7.6dB


Application
Rack to rack
Data centers Switches and Routers
Metro networks
Switches and Routers
40G BASE-LR4 Ethernet Links
