Key Features
Up to 11.2Gbps per channel bandwidth
Aggregate bandwidth of > 40Gbps
Duplex LC connector
Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-SR4 and 40GBASE-IR4 Standard
QSFP MSA compliant
Maximum link length of 140m on OM3 and 160m on OM4
4 CWDM lanes MUX/DEMUX design
Compliant with QDR/DDR Infiniband data rates
Single +3.3V power supply operating
Built-in digital diagnostic functions
Temperature range 0°C to 70°C
RoHS Compliant Part
TX Power: -7~2.3dBm
Receiver Sensitivity: < -10.5dBm
Powerbudget: 3.3dB

Application
Rack to rack
Data centers Switches and Routers
Metro networks
Switches and Routers
40G Ethernet Links
